• Chinese or English characters optional
• Accuracy can reach ±1%
• Non-contact testing, small size, easy to carry
• Suitable for all variable sizes of pipes’ flow metering
• Built-in Ni-MH rechargeable battery, can work continuously more than 20 hours
• Built-in intelligent printer (EPSON), achieving instant or timing print.
• Standard signal interface RS232
• Main working ambient temperature -20°C~60°C

 Performance parameters:

• The velocity measuring range
• Suitable for measuring evenly, single, stable liquid as water, sea water, sewage, Soda acid liquid, alcohol, various oil
• Suitable for steel, stainless steel, cast iron,copper,PVC,aluminum,FRP, etc. uniform and compact of pipeline
• Sensors mounted points should satisfy upstream 10D, downstream 5D, 30D to the pump outlet (D refers to the pipe diameter)
• Power consumption 2W
• Working power AC220V (optional) or Built-in Ni-MH rechargeable battery
• Charging adopts intelligent charging way, accessing AC220V, showing light green after full.
• Quality 2.5kg
• Equipped with one-piece aluminum alloy protective case, is applicable for terrible field environment

Optional sensors:

Standard small size sensor (magnetic)                     Standard medium sensor (magnetic)

Applicable caliber DN15-100mm                                   Applicable caliber DN50-700mm

Fluid temperature ≤160°C                                              Fluid temperature ≤160°C

Overall dimension 45×30×30mm                                   Overall dimension 60×45×45mm

Quality 75g                                                                     Quality 250g

Standard large sensor

Applicable caliber: DN300-6000mm

Fluid temperature: ≤160°C

Quality 528g

Standard configurations:

Aluminum alloy protection case (420×300×136mm)

The host

Standard medium sensor

Signal cable 5m×2

More details please refer to sales or download the brochure
