Products > Solid Flowmeter > > MT100DLD-SY-TF Solid Flow Meter
Product name : MT100DLD-SY-TF Solid Flow Meter
Price : Negotiable

Online Inquiry         Email Us

  Details:
MT100DLD-SY-TF Solid Flow Meter

               Parameter  Name

SY- TF25

SY- TF100





      SY- TF100F



Measure Range

0-25t/h

30-40t/h

0-100t/h

(200-300t/h)

0-500t/h

(800t/h)

Accuracy

0.5-1.0%·FS

0.5-1.0%·FS

0.5%-1.0%·FS

Power Supply

24V·DC

24V·DC

24V·DC

Signal Output

0-10mA·DC

4-20mA·DC

0-10mA·DC

4-20mA·DC

0-10mA·DC

4-20mA·DC

Load Capability

0-500Ω

0-500Ω

0-500Ω

Medium Temp.

<600℃

<600℃

<600℃

Environment Temp.

-45℃~80℃

-45℃~80℃

-45℃~80℃

Relative Humidity

≤85%

≤85%

≤85%

Atmosphere Pressure

86~106kPa

86~106kPa

86~106kPa

Protection Grade

IP65

IP65

IP65

Weight Of Meter

77kg

93kg

150-300kg

Overall Dimension

 Refer to Diagram1

Refer to Diagram 2

Refer to Diagram 3


(Flowmeter Height 600MM, up and down flange port diameter 200MM )

Note: More details and price please refer to sales or download the brochure
